Polynomial Regression Using TensorFlow 2.x

I have a similar post titled Polynomial Regression Using Tensorflow that used tensorflow.compat.v1 (Which still works as of TF 2.16). But, I thought it would be nicer to redo it with newer TF versions.

I will be skipping all the introductions about polynomial regression and jumping straight to the code. Personally, I prefer using scikit-learn for this task.

Position vs Salary Dataset

Again, we will be using the https://drive.google.com/file/d/1tNL4jxZEfpaP4oflfSn6pIHJX7Pachm9/view

If you are in a Python Notebook environment like Kaggle or Google Colaboratory, you can simply run:

!wget --no-check-certificate 'https://docs.google.com/uc?export=download&id=1tNL4jxZEfpaP4oflfSn6pIHJX7Pachm9' -O data.csv

Code

If you just want to copy-paste the code, scroll to the bottom for the entire snippet. Here I will try and walk through setting up code for a 3rd-degree (cubic) polynomial

Imports

import pandas as pd
import tensorflow as tf
import matplotlib.pyplot as plt
import numpy as np

Reading the Dataset

df = pd.read_csv("data.csv")

Variables and Constants

Here, we initialize the X and Y values as constants, since they are not going to change. The coefficients are defined as variables.

X = tf.constant(df["Level"], dtype=tf.float32)
Y = tf.constant(df["Salary"], dtype=tf.float32)

coefficients = [tf.Variable(np.random.randn() * 0.01, dtype=tf.float32) for _ in range(4)]

Here, X and Y are the values from our dataset. We initialize the coefficients for the equations as small random values.

These coefficients are evaluated by Tensorflow's tf.math.poyval function which returns the n-th order polynomial based on how many coefficients are passed. Since our list of coefficients contains 4 different variables, it will be evaluated as:

y = (x**3)*coefficients[3] + (x**2)*coefficients[2] + (x**1)*coefficients[1] (x**0)*coefficients[0]

Which is equivalent to the general cubic equation:

y=ax3+bx2+cx+d

Optimizer Selection & Training

optimizer = tf.keras.optimizers.Adam(learning_rate=0.3)
num_epochs = 10_000

for epoch in range(num_epochs):
    with tf.GradientTape() as tape:
        y_pred = tf.math.polyval(coefficients, X)
        loss = tf.reduce_mean(tf.square(y - y_pred))
    grads = tape.gradient(loss, coefficients)
    optimizer.apply_gradients(zip(grads, coefficients))
    if (epoch+1) % 1000 == 0:
        print(f"Epoch: {epoch+1}, Loss: {loss.numpy()}"

In TensorFlow 1, we would have been using tf.Session instead.

Here we are using GradientTape() instead, to keep track of the loss evaluation and coefficients. This is crucial, as our optimizer needs these gradients to be able to optimize our coefficients.

Our loss function is Mean Squared Error (MSE):

=1ni=1n(Y_iY_i^)2

Where Yi^ is the predicted value and Yi is the actual value

Plotting Final Coefficients

final_coefficients = [c.numpy() for c in coefficients]
print("Final Coefficients:", final_coefficients)

plt.plot(df["Level"], df["Salary"], label="Original Data")
plt.plot(df["Level"],[tf.math.polyval(final_coefficients, tf.constant(x, dtype=tf.float32)).numpy() for x in df["Level"]])
plt.ylabel('Salary')
plt.xlabel('Position')
plt.title("Salary vs Position")
plt.show()

Code Snippet for a Polynomial of Degree N

Using Gradient Tape

This should work regardless of the Keras backend version (2 or 3)

import tensorflow as tf
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt

df = pd.read_csv("data.csv")

############################
## Change Parameters Here ##
############################
x_column = "Level"         #
y_column = "Salary"        #
degree = 2                 #
learning_rate = 0.3        #
num_epochs = 25_000        #
############################

X = tf.constant(df[x_column], dtype=tf.float32)
Y = tf.constant(df[y_column], dtype=tf.float32)

coefficients = [tf.Variable(np.random.randn() * 0.01, dtype=tf.float32) for _ in range(degree + 1)]

optimizer = tf.keras.optimizers.Adam(learning_rate=learning_rate)

for epoch in range(num_epochs):
    with tf.GradientTape() as tape:
        y_pred = tf.math.polyval(coefficients, X)
        loss = tf.reduce_mean(tf.square(Y - y_pred))
    grads = tape.gradient(loss, coefficients)
    optimizer.apply_gradients(zip(grads, coefficients))
    if (epoch+1) % 1000 == 0:
        print(f"Epoch: {epoch+1}, Loss: {loss.numpy()}")

final_coefficients = [c.numpy() for c in coefficients]
print("Final Coefficients:", final_coefficients)

print("Final Equation:", end=" ")
for i in range(degree+1):
  print(f"{final_coefficients[i]} * x^{degree-i}", end=" + " if i < degree else "\n")

plt.plot(X, Y, label="Original Data")
plt.plot(X,[tf.math.polyval(final_coefficients, tf.constant(x, dtype=tf.float32)).numpy() for x in df[x_column]]), label="Our Poynomial"
plt.ylabel(y_column)
plt.xlabel(x_column)
plt.title(f"{x_column} vs {y_column}")
plt.legend()
plt.show()

Without Gradient Tape

This relies on the Optimizer's minimize function and uses the var_list parameter to update the variables.

This will not work with Keras 3 backend in TF 2.16.0 and above unless you switch to the legacy backend.

import tensorflow as tf
import numpy as np
import pandas as pd
import matplotlib.pyplot as plt

df = pd.read_csv("data.csv")

############################
## Change Parameters Here ##
############################
x_column = "Level"         #
y_column = "Salary"        #
degree = 2                 #
learning_rate = 0.3        #
num_epochs = 25_000        #
############################

X = tf.constant(df[x_column], dtype=tf.float32)
Y = tf.constant(df[y_column], dtype=tf.float32)

coefficients = [tf.Variable(np.random.randn() * 0.01, dtype=tf.float32) for _ in range(degree + 1)]

optimizer = tf.keras.optimizers.Adam(learning_rate=learning_rate)

def loss_function():
  pred_y = tf.math.polyval(coefficients, X)
  return tf.reduce_mean(tf.square(pred_y - Y))

for epoch in range(num_epochs):
    optimizer.minimize(loss_function, var_list=coefficients)
    if (epoch+1) % 1000 == 0:
        current_loss = loss_function().numpy()
        print(f"Epoch {epoch+1}: Training Loss: {current_loss}")

final_coefficients = coefficients.numpy()
print("Final Coefficients:", final_coefficients)

print("Final Equation:", end=" ")
for i in range(degree+1):
  print(f"{final_coefficients[i]} * x^{degree-i}", end=" + " if i < degree else "\n")

plt.plot(X, Y, label="Original Data")
plt.plot(X,[tf.math.polyval(final_coefficients, tf.constant(x, dtype=tf.float32)).numpy() for x in df[x_column]], label="Our Polynomial")
plt.ylabel(y_column)
plt.xlabel(x_column)
plt.legend()
plt.title(f"{x_column} vs {y_column}")
plt.show()

As always, remember to tweak the parameters and choose the correct model for the job. A polynomial regression model might not even be the best model for this particular dataset.

Further Programming

How would you modify this code to use another type of nonlinear regression? Say,

y=abx

Hint: Your loss calculation would be similar to:

bx = tf.pow(coefficients[1], X)
pred_y = tf.math.multiply(coefficients[0], bx)
loss = tf.reduce_mean(tf.square(pred_y - Y))
